Mainboard MSI B860M GAMING PLUS WIFI DDR5 LGA1851

SKU: DTB350

Stocking

INTRODUCE

The MSI B860M GAMING PLUS WIFI is a gaming mATX motherboard with the Intel B860 chipset for Intel Core Ultra Processors (Series 2) on Socket LGA1851. It has a 12+1+1+1 Duet Rail Power System with P-PAK and DDR5 up to 8800 MT/s (OC). PCIe 5.0, a Lightning Gen5 M.2 slot, Thunderbolt 4, full-speed Wi-Fi 7, Intel Killer 5G LAN and supplemental PCIe power are all built in.

4,130,000 Kip

Product Details

Brand: MSI
Model: B860M GAMING PLUS WIFI

Features
Ultra Performance: 12+1+1+1 Duet Rail Power System with P-PAK, 8+4-pin CPU power connectors, Core Boost, Memory Boost and a 6-layer server-grade PCB
DDR5 Memory: 4 DDR5 UDIMM slots up to 256 GB and 8800 MT/s (OC)
Lightning Fast Game Experience: PCIe 5.0 slot and Lightning Gen 5 x4 M.2
Triple M.2 Connectors: 3 M.2 slots, including one PCIe 5.0 slot with M.2 Shield Frozr
EZ M.2 Shield Frozr II: A new tool-less design for easy M.2 heatsink installation
Thunderbolt 4: A 40Gbps port with 8K display support and 15W charging
Wi-Fi 7 & Intel Killer 5G LAN: Full-speed Wi-Fi 7 and 5G LAN for fast, stable networking
Supplemental PCIe Power: Extra power for high-end graphics cards
Front USB Type-C: A front USB 10Gbps Type-C connector

Specification
CPU Support: Intel Core Ultra Processors (Series 2)
CPU Socket: LGA1851
Chipset: Intel B860
Power Design: 12+1+1+1 Duet Rail Power System with P-PAK, 8+4-pin CPU power connectors
Memory: 4 × DDR5 UDIMM, max 256 GB; DDR5 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; dual channel; supports UDIMM and CUDIMM
Expansion Slots: 4 × PCI-E x16 slots; PCI_E1 PCIe 5.0 up to x16 (From CPU); PCI_E2 PCIe 4.0 up to x1 (From Chipset); PCI_E3 PCIe 4.0 up to x1 (From Chipset); PCI_E4 PCIe 4.0 up to x4 (From Chipset)
Onboard Graphics: 1 × HDMI 2.1 (max 4K 60Hz), 1 × DisplayPort 1.4 (max 4K 60Hz); available only on processors featuring integrated graphics
Storage: 3 × M.2; M.2_1 (From CPU) supports up to PCIe 5.0 x4, 2280/2260/2242; M.2_2 (From Chipset) supports up to PCIe 4.0 x4, 2280/2260; M.2_3 (From Chipset) supports up to PCIe 4.0 x2, 2280; 4 × SATA 6G
RAID: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Onboard Thunderbolt: 1 × Thunderbolt 4 port (Rear); up to 40Gbps with Thunderbolt devices, up to 20Gbps with USB4 devices, up to 10Gbps with USB 3.2 devices; supports up to 5V/3A, 15W power charging; each port can daisy-chain up to
